Hiroshima Production department

Machine Manufacturer Model Screw dia. Number
Injection Machine SUMITOMO SE18D Φ16 1
SE18S Φ16 3
SE30D Φ20 2
SE30DU Φ18 1
SE30DU Φ20 3
SE30DU Φ22 1
SE30S Φ20 7
SE50D Φ22 1
SE50D Φ25 1
SE50DU Φ18 1
SE50DU Φ20 1
SE50DU Φ22 3
SE50DU Φ25 6
SE50DU Φ28 2
SE50S Φ22 1
SE50S Φ25 1
SE75DU Φ25 1
SE75DU Φ28 1
SE75DUZ Φ28 1
SE75EV Φ25 5
SE75EV Φ28 1
SE100DU Φ32 1
NISSEI PS40 E5A Φ22 4
PS40 E5A Φ26 1
NEX30-2E Φ16 1
NEX30-2E Φ19 1
NEX80-18E Φ28 4
NEX110-18E Φ32 1
FNX110 φ32 1
JSW JT100REⅡ-80V *Vertical type Φ28 1
J110AD Φ32 2
J85AD Φ28 1
J110ELⅢ Φ32 1
FANUC S2000i15A Φ16 1
S2000i30A Φ20 2
S2000i100B Φ32 2
α-S100iA Φ32 7
α-S100iA Φ36 1
α-S100iBJ Φ32 1
α-S130iA Φ32 7
α-S130iB Φ32 1
TOSHIBA EC220-6A φ45 1
Total 86
Measuring Instrument
Profile Projector Nikon V-16E 1
Measuring Microscope Nikon MM-11 1
MM-400/M・MM400/LT 3
MM-60・MM60/L3 2
MM-800 2
Stereo Microscope Nikon SMZ-645 6
SMZ-1B 2
SMZ-445 21
Others 2
OLYMPUS SZ40 23
Others - 4
3D measurement machine Mitutoyo BRT504 1
Image dimensional measurement machine KEYENCE IM-6700/6225 1
Digital microscope KEYENCE VHX-5000 1
Non-contact 3D measurement machine OGP SMARTSCOPE ZIP-250 1
One-shot 3D shape measurement machine KEYENCE VR-3000/VR-3200 1
CNC image measurement machine Nikon iNEXIV VMA-2520 2
Machine Tools
Forming Grinder NICCO F-515HDⅡ 1
Upright drilling machine KIRA KRT-340 1
Incidental
CAD/CAM KODAMA TOP SOLID *3D CAD 5
TOP MOLD *3D CAD 1
Moldflow MPI *Flow analysis software 1

Kyoto Production department

Machine Manufacturer Model Screw dia. Number
Injection Machine SUMITOMO SE180DU Φ45 1
SE180D Φ45 1
SE130EV Φ36 5
SE100DUZ Φ32 2
SE230S Φ50 2
SE130EVHP Φ28 1
東芝 EC40N-1Y Φ22 1
EC60N-1.5Y Φ25 1
EC160-4Y Φ36 1
FANUC S-2000i 50B Φ22 1
S-2000i 30B Φ20 1
α-S130iA Φ32 1
α-S130iB Φ32 1
α-S100iA Φ32 2
α-S50iA Φ28 1
α-S50iA Φ22 2
α-S50iB Φ18 1
α-S50iB Φ16 1
α-S30iA Φ20 1
Total 27

Shiroyama Plant

Machine Manufacturer Model Screw dia. Number
Injection Machine SUMITOMO SE130EV Φ36 1
SE100EV Φ32 1
FANUC α-S130iB Φ36 1
α-S100iA Φ32 2
α-S100iB Φ32 3
α-S50iBJ Φ16 2
α-S50iBJ Φ18 1
Total 11
Measuring Instrument
Profile Projector Nikon V-12BDC 1
V-16E 1
V-20B 1
Measuring Microscope Nikon MM-800 1
MM-400/M・MM-400/LT・MM-400/LFA 3
MM-11 2
Mitutoyo MF-510 1
Stereo Microscope Nikon SMZ-1B 2
SMZ-645 4
OLYMPUS SZ40 2
SZ4045 4
SCALAR VL-11SL(Video loupe) 1
Carton DSZT44iF 1
MICROSCOPE NETWORK - 15
Others - 1
Image dimensional measurement machine KEYENCE IM-7000/7030 1
IM-7000/7030T 1
IM-8000/8030 1
Digital microscope KEYENCE VHX-6000 1
Non-contact 3D measurement machine OGP SMARTSCOPE ZIP-250 1
SMARTSCOPE ZIP-300 1

Engineering Department(Molds)
List of Mold Machining Tools and Measurement Instruments Owned

Machine Manufacturer Model Number
Machine Tools
Forming Grinder NICCO F-515HDⅡ 1
NSG-515HDⅡ 4
NFG-515HD 3
Surface Grinder OKAMOTO PSG-63DX 1
CNC Grinder NICCO F-515CNC-DREAM 1
Manual High-speed Small-hole Drilling EMD SODICK AG40L 2
A30R 1
AQ55L 1
Wire Cut Electrical Discharge Machine SODICK ALN400G 1
AQ325L 1
High-speed Vertical Machining Center TOSHIBA MACHINE F Mach 4421 1
Vertical Machining Center MAKINO V22A *AWC specification (20 sets) 1
V22 1
V33i 1
High-speed Vertical Machining Center TOSHIBA MACHINE F Mach 4421 1
Electrical Discharge Holding SODICK K1C 1
High Precision Machining Center Shibaura Machine UVM-450D(H) 1
Jig Milling MAKINO KVP-55 1
Small-diameter Precision Grinder Meteor MM10 1
Tool Grinding Machine SAKAZAKI SG-V10 1
Upright drilling machine KIRA KRTG-540 1
Contour Machine NCC NCC-300LE 1
Surface modification treatment equipment IEPCO PEENMATIC620S 2
SODICK PF32A 1
Laser marker GATE JAPAN GJ-FLM20-01-006 1
Incidental
CAD/CAM JBM MASTER CAM 2
CGS CAM-TOOL 1
KODAMA TOP MOLD *3D CAD 1
TOP SOLID *3D CAD 12
TOP ELECTRODE 2
ANDOR CAD super JX *2D CAD 2
TORAY 3D TIMON 1

VERTEX INTERNATIONAL(VIT)

Machine Manufacturer Model Number
Injection Machine FANUC α-S150iA 2
α-S100iA 2
S2000i50A 2
S2000i30A 2
SUMITOMO SE75DUZ 1
SE50DU 5
SE30D 1
SE18S 3
SE18D 1
NISSEI TNX75R9V 1
Total 20
Printing Machine
Pad Printing Machine NAVITAS NS-20 5
Machine Tools
Forming Grinder NICCO F-515ADⅡ 1
F-515HDⅡ 5
F-515HD 3
NSG-515HDⅡ 2
CNC High Precision Forming Grinder AMADA MEISTER G3 1
Manual High-speed Small-hole Drilling EMD SODICK AD25L 1
A30R *SN Circuit Equipped 2
AD35L 1
AG40L *Shuttle ATC 1
Wire Cut Electrical Discharge Machine SODICK VZ300L 1
Vertical Machining Center MAKINO V22A *ATC/AWC 1
V33A *ATC 1
Electrical Discharge Holding SODICK K1C 1
Jig Milling MAKINO KVSP-55 1
ENSHU VF-2 1
Tool Grinding Machine SAKAZAKI SG-V10 1
Measuring Instrument
Profile Projector Nikon V-12B 1
V-20B 2
Measuring Microscope Nikon MM-400/M・MM400/LT 3
Stereo Microscope Nikon SMZ-645 3
Digimicro Nikon MF-501 7
ME-501A 6
Micrometers Mitutoyo MDC-25MJ 2
MDC-25SB 2
MDC-50MJ 1
Incidental
CAD/CAM Missler Software Topsolid 3
GENETEC MASTER CAM *CAM 1
ANDOR NASUKA *CAM 1
